Display Screen: 16:9 Colored Analog LCD
Size of Display Screen: 7 inches
Display Screen Pixel: 800*480
Viewing Angle: 65/65/40/65
Brightness: 250
Power Supply: DC15V 1200MA
Operating Power: 8W
Auto Shut-off: 1 minute on monitoring and 2 minutes on intercom.
Intercom Sensitivity: -60dB
Ring Tone: 16 chord ring tones
Operating Temperature: -20°C~+50°C
Idle Temperature: -35°C~+65°C
Dimension: 240(L)*160(W)*28(D)mm
Weight: 440g
Weight of Power Adapter: 140g
Intercom Delay Time: 120S±10%
Monitoring Delay Time: 40S±10%
Standard Wiring: four-core wire (5m free, Max 300m)
Effective Length of Wire: 50 meters (4*0.65MM²)
Camera Chip: CMOS or CCD
Pixel: 350000
Power: DC12V 1000MA (Powered by indoor unit)
Wire Connection: Four-wired
Power: 4W
Definition: 1MP / 720P
System: PAL or NTSC
Size of Lens: 3.6mm
Angle of Lens: 92°
Light Source at Night: Infrared LED
Operating Temperature: -20°C~+50°C
Idle Temperature: -35°C~+65°C
